1,the winding tube inner diameter: Φ40 - Φ180mm

2,winding paper tube thickness: 1—12mm

3,cutting length: 1-4 m (any)

4,production speed: 8 to 18 m

5,host pcwer: 7.5 kw

6,work pressure: 0. 6 mpa

7,the pipe cutting way: single rand blade Φ120mm

8,fixed-length patterns: infrared fixed length

9,gluing system: make multi layer gluing machine

10,paper feeding system: rake right angles put paper hanger 15-20 floors

11,operator: 2-3

12,host, size: 3500 X 1800 X 1900 mm

13,machinery (gross weight) : 3200 kg (or so)
